ATP’s new high-endurance SD/microSD with low latency
S650 series in native TLC outperforms other cards with 1.6X higher endurance;
The S750 series in pSLC mode achieves twice the lifespan
TAIPEI, Taiwan, July 12, 2022 (GLOBE NEWSWIRE) — ATP Electronics, the global leader in specialized memory and storage solutions, introduces its new 3D Triple Level Cell (TLC) SD and microSD series memory cards S750/S650 designed for the extreme demands of non-stop video recording. They meet the high endurance, low latency, and long-lasting data storage requirements of dashcams and digital video recorders (DVRs), as well as surveillance systems, autonomous vehicles, and other write-intensive applications.
High endurance over 109,000 hours1 of recording time in native TLC
Video evidence can prove critical in many scenarios; Therefore, it is very important that SD/microSD cards record continuously without compromising image quality and integrity. The S650 series can continuously record Full HD video for up to 109,401 hours – far longer than similar cards marketed as “high endurance”. The S650 series is based on 5,000 program/erase (P/E) cycles, which means a 1.6 times higher endurance than typical memory cards with 3,000 P/E cycles. Configured as a pseudo single-level cell (pSLC), the S750 series is based on 60,000 P/E cycles, while typical pSLC memory cards are designed for around 20,000 to 30,000 P/E cycles.
The graphic below2 shows the endurance simulation result of the ATP S650 128 GB microSD compared to other high-endurance brand cards of the same capacity in Full HD mode.
Maximum high endurance recording hours: ATP S650 compared to other high endurance cards
1 Tested with 128GB ATP S650 TLC card based on 13Mbps (lowest bitrate of HD recording) in best case/ideal scenario, no other influencing factors.
2 Information obtained by ATP from publicly available data.
- To record new data, the oldest data will be overwritten when the card is full.
- 1Mbps = 1,000,000bps
Low Latency: Ready to shoot in
After switching on, Drive Recorders may have to wait a few seconds before they are ready to record. The time between the first read command and the first write command from the host is the “response time”. ATP S650 and S750 series cards require less than 1 second response time while regular cards require 7 to 12 seconds based on real world testing on a DVR at room temperature.
Recording 16MB of data sequentially, ATP S650 cards take less than 0.1 second, saving 50% of write time compared to consumer-rated cards and enabling high-speed backup without data loss.
Proprietary HW/FW design features provide precise reliability
As a true manufacturer with its own hardware/firmware capability, ATP can adapt to a variety of applications to meet customers’ specific application needs and conditions. Based on customers’ applications, ATP does its best to meet the requirements through unique FW and HW design.
- Auto-Read Calibration (ARC). Over time and constant use, NAND flash memory cells degrade, resulting in voltage shifts that increase bit error rates (BER). When the normal Read Retry function is not sufficient to recover from the errors, a more precise “Auto Read Calibration” (ARC) is applied to ensure data integrity in the event of extreme temperatures or degraded NAND cells.
- ATP methodology for advanced map analysis. ATP memory cards are IP67/IP57 certified and manufactured using the System-in-Package (SiP) wafer/die process, making component analysis more difficult compared to the SMT (Surface-Mount Technology) process. ATP’s uniquely designed substrate and debug tool make this mission “possible”.
- Hardware design developed by ATP – substrate with reserved test pin is available for future component analysis.
- Laser Solder Mask Removal – Precise and efficient method of removing the solder mask to reach the reserved test pins on the substrate.
- ATP’s own customized debug tool – This is connected to the test pin reserved for HW and then linked to the SW analysis system.
For more information on ATP’s advanced map analysis method, visit: https://www.youtube.com/watch?v=89Lm_eC3mSU
|flash guy||3D pSLC||3D pSLC||3D TLC||3D TLC||3D pSLC||3D pSLC||3D TLC||3D TLC|
|form factor||SD card||MicroSD card|
|operating temperatur||-40℃ to 85℃||-25ºC to 85ºC||-40℃ to 85℃||-25ºC to 85ºC||-40℃ to 85℃||-25ºC to 85ºC||-40℃ to 85℃||-25ºC to 85ºC|
|Power failure protection options||Firmware based||Firmware based|
|capacity||8GB to 32GB||8GB to 32GB||32GB to 128GB||32GB to 128GB||8GB to 64GB||8GB to 64GB||32GB to 256GB||32GB to 256GB|
|Sequential Read (MB/s) up to||99||99||96||96||99||99||96||96|
|Sequential Write (MB/s) up to||78||78||62||62||82||82||65||65|
|Endurance (TBW)1 up to||1920||1920||640||640||3840||3840||1280||1280|
MTBF at 25°C
|>2,000,000 hours||>2,000,000 hours||>2,000,000 hours||>2,000,000 hours||>2,000,000 hours||>2,000,000 hours||>2,000,000 hours||>2,000,000 hours|
number of insertions
|20,000 (SDA specification at least 10,000)||20,000 (SDA specification at least 10,000)|
|Dimensions: L x W x H (mm)||32.0 x 24.0 x 2.1||32.0 x 24.0 x 2.1||32.0 x 24.0 x 2.1||32.0 x 24.0 x 2.1||15.0 x 11.0 x 1.0||15.0 x 11.0 x 1.0||15.0 x 11.0 x 1.0||15.0 x 11.0 x 1.0|
|certifications||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS||CE, FCC, UKCA, RoHS|
|warranty||5 years||2 years||3 years||3 years||5 years||2 years||3 years||3 years|
|1 Below the highest sequential write value. May vary based on density, configuration and applications.|
For customers who require application-specific functionality or technology, ATP offers value-added customization services that include firmware and hardware, as well as packaging and appearance (labels, printing, and marking).
For more information on the S750/S650 series SD/microSD cards, please visit:
Press release media contact: Kelly Lin ([email protected])
Follow ATP Electronics on LinkedIn: https://www.linkedin.com/company/atp-electronics
ATP Electronics (“ATP”) has been the leading provider of memory and NAND flash memory products for demanding embedded/industrial/automotive applications for 30 years. As a “Global Leader in Specialized Storage and Memory Solutions”, ATP is known for its expertise in thermal and durable solutions. ATP strives to bring value, differentiation and the best TCO to its customers. As a true manufacturer, ATP manages every stage of the manufacturing process to ensure the quality and longevity of the product. ATP upholds the highest standards of corporate social responsibility by ensuring sustainable worker, environmental and corporate values throughout the global supply chain. For more information about ATP Electronics, please visit www.atpinc.com or contact us at [email protected]
